O'reilly Architecture

From O'reilly Neal Ford & Mark Richards presentation. These are one of several interesting points:

Trends 2017

From infoq:

Now, we should see 2018 trends :)

Garbage Collector incompatibilities

Garbage Collector incompatibilities

Conflicting collector combinations in option list; please refer to the release notes for the combinations allowed

I got the above error message after upgrading Eclipse Oxygen.

This is for GC options:

-XX:+UseParallelGC
# -XX:+UseG1GC

We cannot use both Garbage Collector at the same time... at least in this new version 4.7.2

https://docs.oracle.com/javase/8/docs/technotes/guides/vm/gctuning/collectors.html

Spring Singleton & Concurrency

A good post with Java champs about Singleton, concurrency, instance variables & static:

http://richardchesterwood.blogspot.cl/2011/03/using-sessions-in-spring-mvc-including.html

https://stackoverflow.com/questions/37595841/spring-scope-usage-for-instance-variables

@Scope(scopeName = BeanDefinition.SCOPE_PROTOTYPE, proxyMode = ScopedProxyMode.TARGET_CLASS)

https://coderanch.com/t/661307/framework/singleton-concurrent-access

https://docs.spring.io/spring/docs/3.0.0.M3/reference/html/ch04s04.html

Datasource Sizing - Queuing Theory

To obtain the correct number for a connection Datasource pool, first, we may need to understand queue theory and have good observability of the data source itself and from there take decisions.

Said that I'd like to review once again the Little's law (from Queuing Theory)

L – average number of customers
λ – long-term average arrival rate
W – average time a request spends in a system

L : Número promedio de clientes en un sistema
λ : Número promedio de clientes que llegan al sistema por unidad de tiempo
W : Tiempo promedio de espera en un sistema



• https://vladmihalcea.com/2014/05/20/the-simple-scalability-equation/
• https://en.wikipedia.org/wiki/Little%27s_law
• https://www.gestiondeoperaciones.net/lineas-de-espera/que-es-la-ley-de-little-y-su-aplicacion-en-el-analisis-de-lineas-de-espera/

• https://vladmihalcea.com/the-anatomy-of-connection-pooling/

• https://stackoverflow.com/questions/1208077/optimal-number-of-connections-in-connection-pool
• https://github.com/brettwooldridge/HikariCP/wiki/About-Pool-Sizing
• http://xmlandmore.blogspot.com/2012/10/dynamically-sizing-jdbc-connection-pool.html
• https://vladmihalcea.com/2014/04/25/flexy-pool-reactive-connection-pooling/
• https://vladmihalcea.com/2014/04/30/professional-connection-pool-sizing-with-flexy-pool/


Patrones de Diseño (en un año)

Se han utilizado diferentes patrones de diseño para diferentes necesidades, tal como, de arquitectura de componentes a nivel de servicios y de patrones de construcción OOP.

A continuación es la lista de los patrones de diseños usados:

- Descomposición de servicios para poder tener un buen limite de dominios (DDD, separation of concerns)

- @Domains: usado en la capa Rest donde está la implementación de POJOs

- Repository: donde está desacoplado la implementación de varios repositorios, dejando expuesta el mismo contrato a los cliente.

- @Service: capa Rest, tiene Patrón: Service-layer, en donde implementamos diferentes servicios para llamar, sean base datos pertenecientes a CDN o directamente como cliente al bus de servicios.

- @Controller: Rest, es el controller de springmvc, que es parte del patrón de diseño MVC, el cual dejamos claro el manejo del flujo del servicio rest

- Factory: todos los datasources utilizados vienen del contenedor de aplicaciones (Weblogic), y es una factoría de la cual nos abstraemos de la implementación (Oracle) y usamos la conexión entregada, la cual es reutilizada en las siguientes interacciones.

- DAO: pl-generator, librería que genera DAO automático desde la metadata de oracle y tenemos la interfaz (Façade) de los stored procedures de la base de datos, por directriz (generalmente en bancos) siempre accedemos a través de esos SP, y la librería gracias a esta encapsulación entregada por DAO podemos abstraernos de todo lo necesario de conexiones JDBC.

- SAL: Service Access Layer: Rest, patrón que viene desde la arquitectura SOA y tenemos implementada los diferentes servicios en un solo package.

- MVC: angular/rest. Usamos el patrón Model-View-Controller en nuestra solución. View es AngularJS, Controller y Model está implementado en Rest en las clases con anotaciones @Controller y Pojos, aprovechando la separación entregada por Spring

- API-Proxy: Usamos servicios Rest para todos los accesos desde front hacia OSB/DB. nunca se puede acceder directo desde Front, asi se usa api-proxy como interfaz.

- Aggregator: se utiliza en message-aggregator-rest para encapsular la implementación de del motor de envio de emails. De esta manera le damos más valor al request del envío del correo (Decorator) y tenemos un fachada (facade) para la implementación final.

- Connection Factory: JMS, todos los JMS utilizan un Connection Factory implementada por WLS. de esta manera se reutilizan las conexiones JMS.

- Prototype: en javascript para extender funciones y hacer honor al límite de 100 líneas por función (modular), se utiliza el patrón prototype.

- Database per service: notificaciones utiliza 1 schema por su solución, y no compartimos la base de datos con otros servicios, si alguien más necesita insertar datos estos deben hacerse a través un el api-proxy expuesto por notificaciones.

- Shared database (base datos compartida), existen schemas que son utilizados por varios servicios, tal como, session_cn.

- Log aggregation, se logea las transacciones y funcionalidades importantes de cada uno de los servicios en un log de aplicación que está configurado en cada uno de los dominios de WLS.

- Client-side UI composition. Cada aplicación puede tener componentes propios que están encapsulados en directivas angular. Estas directivas pueden ser reutilizadas por otras aplicaciones. El equipo de Diseño se preocupa de generar el esqueleto de las páginas, componiendo diferentes componentes UI.

- además utilizamos de varios patrones de diseño de más bajo nivel GoF: iterator, façade, singleton, Factory method pattern, Decorator, Builder, etc.

Java Performance

This is a summary post of good practices (many easy) to improve performance in your Java code:

1. use Apache commons-lang StringUtils.replace() instead String.replace(). The big difference is because Java replace() uses regexp which makes it more expensive immediately.
2. avoid regexp if possible (many times we use regexp and meanwhile a String.indexof() is enough).  also, Apache commons lang: StringUtils.replace("hola\nmundo\n", "\n", "");
3. Compile once a Regexp Pattern:  Pattern pattern_dst = Pattern.compile("destinationAddress\\\"\\:\\\"[0-9]+\\.[0-9]+\\.[0-9]+\\.[0-9]+\\\"");

4. Apache commons lang, now has separated packages for regexp methods, such us, replaceall().
5. on the same, String.split also has issues when it's not a simple character the splitter
6. avoid using Java7 UUID (there are other faster libraries for it) (randomness trends to be slow).
   https://github.com/cowtowncoder/java-uuid-generator
   https://github.com/jchambers/fast-uuid    (* this looks interesting)
   https://github.com/codahale/fast-uuid
7. Asynchronous Logging Parameterized Messages (log4j2) (Ring buffer - LMAX Disruptor)
   Many logging libraries offer an API for logging parameterized messages. This enables application code to look something like this:
   logger.debug("Entry number: {} is {}", i, entry[i]);
   without API:

   if (logger.isDebugEnabled()) {
       logger.debug("Entry number: " + i + " is " + entry[i].toString());
   }

   The best solution is placeholders and if{}

   if (logger.isDebugEnabled()) {
       logger.debug("Entry number: {} is {}", i, entry[i]);
   }
   lambda java8:
   logger.trace("Some long-running operation returned {}", () -> expensiveOperation());

8. Jasper Reports has a lazy loading at init() :
   JasperReportsContext jasperReportsContext = new SimpleJasperReportsContext();
           LocalJasperReportsContext localJasperReportsContext = new LocalJasperReportsContext(jasperReportsContext);
           localJasperReportsContext.setClassLoader(this.getClass().getClassLoader());
9. StringBuilder or StringBuffer over String (for concatenation)
10. Primitive over wrapper, such us, Integer, Double etc, ie:
    The Integer class wraps a value of the primitive type int in an object. An object of type Integer contains a single field whose type is int.
    If you need an object instead, then use Integer.valueOf(), Long.valueOf()
11. Sorted of sorted List Java sorted ??? (Big Theta!)
12. String concatenating one line, it's not a problem
13. BigInteger & BigDecimal are expensive. (avoid)
14. Cache database connections. Object pooling. Apache common pool, Fast Object Pool, Vibur Object Pool
15. Tune fetchSize when querying a big number of rows from DB. (default is 10, which makes it slow)
16. Mapper Objects: use MapStruct (fastest).
17. log4j contention when writing to log file (async, buffer, network as a solution)
18. exceptions are "expensive"
19. Timeouts! (trigger'm!)
    Socket_timeouts TCP_NODELAY, SO_SNDBUF, SO_RCVBUF,  HTTP, JAX-WS, RestTemplate, JDBC timeouts :P
20. Thread synchronized (as seen on log4j2), blocking java monitor
21. HTTP 1.1 instead 1.0 (keep-alive)
22. Data source sizing
23. PMD has several performance rules:  (among others)
    Don’t create instances of already existing BigInteger (BigInteger.ZERO, BigInteger.ONE)
    Avoid instantiating Boolean objects; you can reference Boolean.TRUE, Boolean.FALSE.
24. Most of PMD, checkstyles rules are embedded at sonarqube.
25. Jackson ObjectMapper must be reused (it's thread-safe). It is expensive.(use 2.8.7+ by race condition). Singleton, static or Object pooling (see above).
26. CompletableFuture uses a forkjoin thread pool, which is a thread pool shared between all CompletableFutures and all parallel streams.
    https://dzone.com/articles/concurrency-in-action-using-javas-completable-futu
27. https://github.com/devwebcl/async-springmvc-poc
28. Java 8 parallel streams pitfall
    https://www.baeldung.com/java-8-parallel-streams-custom-threadpool https://medium.com/@michaelbespalov/parallel-stream-pitfalls-and-how-to-avoid-them-91f11808a16
29. JVM CPU measure. It may be expensive for some JVM
30. Every time you make something "static", consider if you want to make it "final" too. In most cases, you do. "static final"-s are much more optimize-able. https://t.co/Xm0YgDUTtL (from @shipilev)
31. Netty is a popular asynch framework, but it can suffer of OOM: io.netty.maxDirectMemory
32. DO NOT use java 11 (~30% slower)


try-with-resources

A known, and now kind of old feature of Java 7, but still isn't as popular as we wish.

Straightforward (and easy) implementation, where you need to declare resources (File, Stream) into parenthesis of "try" keyword:

private static void printFileJava7() throws IOException {

    try(InputStream input = new FileInputStream("hola.txt")) {

        int data = input.read();
        while(data != -1){
            System.out.print((char) data);
            data = input.read();
        }
    }
}

And JVM will have the responsibility to close those resources.

Beware: that the object in try() must implement AutoCloseable.

More info:

https://docs.oracle.com/javase/tutorial/essential/exceptions/tryResourceClose.html

http://tutorials.jenkov.com/java-exception-handling/try-with-resources.html

https://www.mkyong.com/java/try-with-resources-example-in-jdk-7/

HTTP Codes - Arquitectura Restful

La arquitectura Rest se basa fuertemente en el protocolo HTTP, por lo cual es importante responder (y parsear al recibir) los diferentes códigos HTTP que existen.
Los códigos están agrupados por las siguientes categorías:

• 1xx – Informational
• 2xx – Successful
• 3xx – Redirection
• 4xx - Client Error
• 5xx - Server Error

El proyecto  deberia uso granular de estos códigos con alguna libreria transversal.

Deberíamos usar solo los códigos más útiles (top “10”) que son los siguientes:

HTTP Response codes

200	OK	Successfully executed. should be used to indicate nonspecific success
201	CREATED	Successfully executed and a new resources has been created. The response body is either empty or contains a URI(s) of the created resource. The location header should should also contain the new URI
202	ACCEPTED	The request was valid and has been accepted but has not yet been processed. The response should include a URI to poll for status updates on the request. Allows for asynchronous request ( start of an asynchronous action)
204	NO_CONTENT	The request was successful but the server did not have a response. should be used when the response body is intentionally empty. Ejemplo: Si se busca el listado de productos para un cliente y el cliente existe pero la lista es vacía, el estado es 204
301	MOVED_PERMANENTLY	The new location should be returned in the response ( should be used to relocate resources)
302	REDIRECT	The HTTP response status code 302 Found is a common way of performing URL redirection.
400	BAD_REQUEST	Malformed or invalid request
401	UNAUTHORIZED	Invalid authorization credentials. (no autenticado, o autenticado incorrectamente)
403	FORBIDDEN	Disallowed request. Security error. (no autorizado para ver pagina/recurso)
404	NOT_FOUND	Resource not found. Ejemplo: Si se busca un cliente por rut y éste no existe, el estado es 404
405	METHOD_NOT_ALLOWED	Method (verb) not allowed for requested resource. Response will provide an “Allow” header to indicate what is allowed
412	PRECONDITION_FAILED	One or more conditions given in the request header fields evaluated to false when tested on the server.
415	UNSUPPORTED_MEDIA_TYPE	Client submitted a media type that is incompatible for the specified resource.
422	UNPROCESSABLE_ENTITY	Se ha producido un error funcional. El servicio reconoce los parámetros como válidos, pero alguna condición de negocio no se puede llevar a cabo. Ej: "Monto Pagado+monto capitalizado no puede ser mas que monto adeudado+monto vencido+monto adeudado ajuste-monto condonado para monto XXX" invocando a servicio bus para cálculo de pago.
418	I'm a teapot	Ludic HTTP
500	INTERNAL_SERVER_ERROR	Catchall for server processing problem
503	SERVICE_UNAVAILABLE	Response in the face of too many request
504	GATEWAY_TIMEOUT	server error response code indicates that the server, while acting as a gateway or proxy, did not get a response in time from the upstream server that it needed in order to complete the request.

HTTP verbs:


1. GET. The GET method requests a representation of the specified resource. Requests using GET should only retrieve data. (idempotent)
2. POST. The POST method is used to submit an entity to the specified resource, often causing a change in state or side effects on the server (payload)
3. HEAD. The HEAD method asks for a response identical to that of a GET request, but without the response body.
4. PUT. The PUT method replaces all current representations of the target resource with the request payload.
5. DELETE. The DELETE method deletes the specified resource.
6. CONNECT. The CONNECT method establishes a tunnel to the server identified by the target resource.
7. OPTIONS. The OPTIONS method is used to describe the communication options for the target resource.  OPTIONS sirve para verificar CORS!
8. TRACE. The TRACE method performs a message loop-back test along the path to the target resource.

9. PATCH. The PATCH method is used to apply partial modifications to a resource.

more details:

• HEAD - No defined body semantics.
• GET - No defined body semantics.
• DELETE - No defined body semantics.
• CONNECT - No defined body semantics

• PUT - Body supported.
• POST - Body supported.
• TRACE - Body not supported.
• OPTIONS - Body supported but no semantics on usage (maybe in the future).

Mayor información:

•  https://en.wikipedia.org/wiki/List_of_HTTP_status_codes
•  https://hackernoon.com/restful-api-designing-guidelines-the-best-practices-60e1d954e7c9

Spring Batch Samples

Several examples of Spring Batch:

https://github.com/devwebcl/spring-batch

Simple HTTP Server

python -m SimpleHTTPServer 8000

if you face :
/usr/bin/python: No module named SimpleHTTPServer

it's because for python 3:

python3 -m http.server 8000

Cannot retrieve WLS app info

Cannot retrieve:

The configuration for app is still being loaded from your last request, please wait a moment and retry.

####<Oct 30, 2017 9:59:44 AM CLT> <Error> <Console> <lablnx297> <AdminServer> <[ACTIVE] ExecuteThread: '5' for queue: 'weblogic.kernel.Default (self-tuning)'> <weblogic> <> <cc19eb40-e1ae-46e5-80cb-dbf2a3509811-00000f0c> <1509368384819> <BEA-240003> <Administration Console encountered the following error: java.lang.NullPointerException
  at weblogic.application.internal.ApplicationRuntimeMBeanImpl.getComponentRuntimes(ApplicationRuntimeMBeanImpl.java:449)
  at sun.reflect.GeneratedMethodAccessor1348.invoke(Unknown Source)
  at sun.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)
  at java.lang.reflect.Method.invoke(Method.java:606)
  at weblogic.management.jmx.modelmbean.WLSModelMBean.getAttribute(WLSModelMBean.java:525)
  at com.sun.jmx.interceptor.DefaultMBeanServerInterceptor.getAttribute(DefaultMBeanServerInterceptor.java:647)
  at com.sun.jmx.mbeanserver.JmxMBeanServer.getAttribute(JmxMBeanServer.java:678)
  at weblogic.management.jmx.mbeanserver.WLSMBeanServerInterceptorBase$12.run(WLSMBeanServerInterceptorBase.java:326)
  at java.security.AccessController.doPrivileged(Native Method)
  at weblogic.management.jmx.mbeanserver.WLSMBeanServerInterceptorBase.getAttribute(WLSMBeanServerInterceptorBase.java:324)
  at weblogic.management.mbeanservers.internal.JMXContextInterceptor.getAttribute(JMXContextInterceptor.java:157)
  at weblogic.management.jmx.mbeanserver.WLSMBeanServerInterceptorBase$12.run(WLSMBeanServerInterceptorBase.java:326)
  at java.security.AccessController.doPrivileged(Native Method)
  at weblogic.management.jmx.mbeanserver.WLSMBeanServerInterceptorBase.getAttribute(WLSMBeanServerInterceptorBase.java:324)
  at weblogic.management.mbeanservers.internal.SecurityInterceptor.getAttribute(SecurityInterceptor.java:300)
  at weblogic.management.jmx.mbeanserver.WLSMBeanServer.getAttribute(WLSMBeanServer.java:279)
  at weblogic.management.mbeanservers.internal.JMXConnectorSubjectForwarder$5$1.run(JMXConnectorSubjectForwarder.java:327)
  at java.security.AccessController.doPrivileged(Native Method)
  at weblogic.management.mbeanservers.internal.JMXConnectorSubjectForwarder$5.run(JMXConnectorSubjectForwarder.java:325)
  at weblogic.security.acl.internal.AuthenticatedSubject.doAs(AuthenticatedSubject.java:363)
  at weblogic.management.mbeanservers.internal.JMXConnectorSubjectForwarder.getAttribute(JMXConnectorSubjectForwarder.java:320)
  at javax.management.remote.rmi.RMIConnectionImpl.doOperation(RMIConnectionImpl.java:1468)
  at javax.management.remote.rmi.RMIConnectionImpl.access$300(RMIConnectionImpl.java:97)
  at javax.management.remote.rmi.RMIConnectionImpl$PrivilegedOperation.run(RMIConnectionImpl.java:1332)
  at java.security.AccessController.doPrivileged(Native Method)
  at javax.management.remote.rmi.RMIConnectionImpl.doPrivilegedOperation(RMIConnectionImpl.java:1431)
  at javax.management.remote.rmi.RMIConnectionImpl.getAttribute(RMIConnectionImpl.java:661)
  at javax.management.remote.rmi.RMIConnectionImpl_WLSkel.invoke(Unknown Source)
  at weblogic.rmi.internal.BasicServerRef.invoke(BasicServerRef.java:701)
  at weblogic.rmi.internal.BasicServerRef$1.run(BasicServerRef.java:527)
  at weblogic.security.acl.internal.AuthenticatedSubject.doAs(AuthenticatedSubject.java:363)
  at weblogic.security.service.SecurityManager.runAs(SecurityManager.java:146)
  at weblogic.rmi.internal.BasicServerRef.handleRequest(BasicServerRef.java:523)
  at weblogic.rmi.internal.wls.WLSExecuteRequest.run(WLSExecuteRequest.java:118)
  at weblogic.work.ExecuteThread.execute(ExecuteThread.java:311)
  at weblogic.work.ExecuteThread.run(ExecuteThread.java:263)
>

HTTP Cluster WebLogic Server

Old Deprecated feature:

web.xml :

<servlet><servlet-name>ProxyServlet</servlet-name>
<servlet-class>weblogic.servlet.proxy.HttpProxyServlet</servlet-class>
<init-param>
<param-name>redirectURL</param-name>
<param-value>http://localhost:8080</param-value>
</init-param>
</servlet>
<servlet-mapping>
<servlet-name>ProxyServlet</servlet-name>
<url-pattern>/MyProducerApp/*</url-pattern>
</servlet-mapping>

.

Clear Cache WLS

Before deleting any directory, you need to shutdown all servers first.

The following provides a generic example path to the tmp directory in question:

WINDOWS:
cd C:\wls\user_projects\domains\servers\

UNIX:
cd /wls/user_projects/domains/servers/

The following would be used to clear the cache:

WINDOWS:
rd C:\wls\user_projects\domains\servers\tmp
rd C:\wls\user_projects\domains\servers\cache

UNIX:
rm -rf /wls/user_projects/domains/servers/tmp
rm -rf /wls/user_projects/domains//servers/cache


 For WLS versions 9.2 and above, delete the following Admin and Managed server cache directories:

    /servers/cache
    /servers/stage (if exists)
    /servers/tmp


WLS JMS Configuration

Essential steps to configure a JMS environment


CORE_WLS_Domain --> Services --> Persistent Stores -->

New:

Name: FileStore-Mensajeria1
Target: Managed Server 1 (WLS01)
Directory: jmsMensajeria_1
(Activate Changes)

Name: FileStore-Mensajeria2
Target: Managed Server 2 (WLSS02)
Directory: jmsMensajeria_2
(Activate Changes)


CORE_WLS_Domain --> Services --> Messaging --> JMS Servers

New:

Name: JMSServer-Mensajeria_1
Persistent Store: FileStore-Mensajeria1
Target: WLS01 (migratable)
(finish)

Name: JMSServer-Mensajeria_2
Persistent Store: FileStore-Mensajeria2
Target: WLS02 (migratable)
(finish)

(Activate Changes)


CORE_WLS_Domain --> Services --> Messaging --> JMS Modules

Name: JMSModule_Mensajeria
Target: wls_core_cluster
(next/finish)
(Activate Changes)


entrar a JMS Module creado: (crear subdeployment)
CORE_WLS_Domain --> Services --> Messaging --> JMS Modules --> JMSModule_Mensajeria --> Subdeployments

New:

name: MensajeriaSubdeployment
Target: JMSServer-Mensajeria_1, JMSServer-Mensajeria_2
(Activate Changes)


CORE_WLS_Domain --> Services --> Messaging --> JMS Modules --> JMSModule_Mensajeria

New:

Connection Factory (next)

Name: ConnectionFactory-Mensajeria
JNDI Name: jms/ConnectionFactory-Mensajeria (next)
(finish)
(Activate Changes)

New:

Distributed Queue (next)

Name: DistributedQueue-Mensajeria
JNDI Name: jms/journal-standar (next)
Advanced Targeting: MensajeriaSubdeployment

JMS Servers: JMSServer-Mensajeria_1, JMSServer-Mensajeria_2
(finish)
(Activate Changes)

Opatch WLS 12c

Backup Oracle Home:
It is highly recommended that you back up the Oracle home before any patch operation. You can back up the Oracle home using your preferred method. You can use any method such as zip, cp -r, tar, and cpio to compress the Oracle home.

Opatch path:
/Users/German/Oracle/Middleware/Oracle_Home/OPatch

List patches:
./opatch lsinventory
./opatch lsinventory -detail

Check if it's feasible:
./opatch apply /Users/German/tmp/patches/23639929 -report

if the next message appears:

JAVA_HOME is not set or does not exist

then add (jre path) :

-jre /Library/Java/JavaVirtualMachines/jdk1.7.0_201.jdk/Contents/Home

Apply patch:
./opatch apply /Users/German/tmp/patches/23639929

Rollback patch
./opatch rollback -id 23639929

logs:

ORACLE_HOME/cfgtoollogs/opatch/

More info:
https://docs.oracle.com/middleware/1213/core/OPATC/toc.htm

Too many open files

The following problem may occurr in WLS:

Caused By: java.net.SocketException: Too many open files
  at java.net.Socket.createImpl(Socket.java:447)
  at java.net.Socket.connect(Socket.java:577)
  at oracle.net.nt.TcpNTAdapter.connect(TcpNTAdapter.java:161)
  at oracle.net.nt.ConnOption.connect(ConnOption.java:159)
  at oracle.net.nt.ConnStrategy.execute(ConnStrategy.java:428)
  at oracle.net.resolver.AddrResolution.resolveAndExecute(AddrResolution.java:506)
  at oracle.net.ns.NSProtocol.establishConnection(NSProtocol.java:595)
  at oracle.net.ns.NSProtocol.connect(NSProtocol.java:230)

This is a common issue when  File Descriptors are not enough for the OS processes.

Checking the most open FD appear WLS Managed Servers and they are almost on the limit:

4076 376 /u04/Middleware/WLS12c/jdk/bin/java-server-Xms1024m-Xmx2048m-XX:PermSize=256m-XX:MaxPermSize=512m-Dweblogic.Name=WLS02

4063 32526 /u04/Middleware/WLS12c/jdk/bin/java-server-Xms1024m-Xmx2048m-XX:PermSize=256m-XX:MaxPermSize=512m-Dweblogic.Name=WLS01

Checking with lsof -p <pid> we see a lot of open jar files from war files, because we have several war files deployed.

Check:

$ ulimit -n
4096

Therefore the solution is to set a bigger soft & hard limit.

How to know OHS version

$ ./httpd.worker -v
./httpd.worker: error while loading shared libraries: libexpat.so.0: cannot open shared object file: No such file or directory

$ ps -fea | grep httpd

$ export ORACLE_HOME=/u04/Middleware/P_OHS12c/product

$ export LD_LIBRARY_PATH=/u04/Middleware/P_OHS12c/product/lib

$ cd /u04/Middleware/P_OHS12c/product/wlserver/../ohs/bin/

$ ./httpd.worker -v
Server version: Oracle-HTTP-Server/2.2.22 (Unix)
Server built:   Sep  3 2015 01:14:57
Server label:   APACHE_12.1.3.0.0_LINUX.X64_RELEASE

Sed cheat sheet

Sometimes we need to clean-up a file (ie: log prod file).

(or gsed for gnu-sed in macosx

* delete a match and backup of original file:

sed -i.bak '/<ConnectionEnv.cleanup, jconn=oracle.jdbc.driver.T4CConnection/d' ./infile

sed -i.bak '/INFO: true/d' ./infile

gsed -i.bak '/INFORMACIÓN: true> /d' ./infile


* delete two lines and the match string

gsed -i -e '/match1/,+2d'

* delete one line and the match string

gsed -i -e '/OPTIONS/,+1d' *uml*.puml

* execute more than one command in sed (use -e flag)

sed -i -e 's/File//g' -e 's/MINvac.pdb//g'

* recursive find and replace

find . -type f -print0 | xargs -0 sed -i 's/MYSQL_USER/MYSQL_ROOT_USER/g'

* no lookups by default

use: -E o -r ( -E, -r, --regexp-extended )

Inputless WLS Credentials

Awkwardly WLS develoment version does not show credentials input when booting.
Of course, the solution is to create security/boot.properties.
however if I don't press [enter] then it waits forever :S

Probably there is a patch for this, but dev version

<Aug 11, 2017 11:30:18 AM CLT> <Info> <Security> <BEA-090906> <Changing the default Random Number Generator in RSA CryptoJ from ECDRBG128 to FIPS186PRNG. To disable this change, specify -Dweblogic.security.allowCryptoJDefaultPRNG=true.>
<Aug 11, 2017 11:30:18 AM CLT> <Info> <WebLogicServer> <BEA-000377> <Starting WebLogic Server with Java HotSpot(TM) 64-Bit Server VM Version 24.80-b11 from Oracle Corporation.>
<Aug 11, 2017 11:30:19 AM CLT> <Info> <Security> <BEA-090065> <Getting boot identity from user.>

---->

<Aug 10, 2017 6:01:49 PM CLT> <Info> <Management> <BEA-141298> <Could not register with the Administration Server: java.rmi.RemoteException: [Deployer:149150]An IOException occurred while reading the input. : with response code '401' : with response message 'Unauthorized'>
<Aug 10, 2017 6:01:49 PM CLT> <Info> <Management> <BEA-141107> <Version: WebLogic Server 12.1.3.0.0  Tue Aug 11 09:00:41 UTC 2015 1697938 >
<Aug 10, 2017 6:01:52 PM CLT> <Error> <Configuration Management> <BEA-150021> <The Administration Server failed to authenticate the identity of the user  starting the Managed Server. The reason for the error is .>
<Aug 10, 2017 6:01:52 PM CLT> <Alert> <Management> <BEA-141151> <The Administration Server could not be reached at http://127.0.0.1:7001.>
<Aug 10, 2017 6:01:52 PM CLT> <Info> <Configuration Management> <BEA-150018> <This server is being started in Managed Server independence mode in the absence of the Administration Server.>
<Aug 10, 2017 6:01:52 PM CLT> <Notice> <WebLogicServer> <BEA-000365> <Server state changed to STARTING.>
<Aug 10, 2017 6:01:52 PM CLT> <Info> <WorkManager> <BEA-002900> <Initializing self-tuning thread pool.>
<Aug 10, 2017 6:01:52 PM CLT> <Info> <WorkManager> <BEA-002942> <CMM memory level becomes 0. Setting standby thread pool size to 256.>

Software Architect Skills/Responsabilities

There are several list of required skills/responsabilities a Software Architect should have.
One of these (a little old now, but still valid) is:

https://dzone.com/articles/architecture-%E2%80%93-top-10-traits

1.     Knowledge of relevant technologies
2.     Strong analysis & design skills
3.     Coding & POCs
4.     Architecture & design activities
5.     Modeling language/Tools
6.     Architectural frameworks/Tools
7.     Communication
8.     Training/Mentoring
9.     Sales/Pre-sales
10.     Presentation Skills

PD: as usual, I'll be updating this Post as I find new resources or my own ideas...

1. Code Review

from Simon Brown:

Java Muxer WLS

Go to Environment > Servers > your_Server > Tuning, under Advanced, set the Muxer Class based on your OS and reboot the server.

Solaris/HP­UX Native Muxer : weblogic.socket.DevPollSocketMuxer
POSIX Native Muxer : weblogic.socket.PosixSocketMuxer
Windows Native Muxer : weblogic.socket.NTSocketMuxer
Java Muxer : weblogic.socket.JavaSocketMuxer

java.lang.Thread.State: RUNNABLE
at sun.nio.ch.EPollArrayWrapper.epollWait(Native Method)
at sun.nio.ch.EPollArrayWrapper.poll(EPollArrayWrapper.java:269)
at sun.nio.ch.EPollSelectorImpl.doSelect(EPollSelectorImpl.java:79)
at sun.nio.ch.SelectorImpl.lockAndDoSelect(SelectorImpl.java:87)
­ locked <0x0000000789f2b040> (a sun.nio.ch.Util$2)
­ locked <0x0000000789f2b030> (a java.util.Collections$UnmodifiableSet)
­ locked <0x0000000789f2adf8> (a sun.nio.ch.EPollSelectorImpl)
at sun.nio.ch.SelectorImpl.select(SelectorImpl.java:98)
at weblogic.socket.NIOSocketMuxer$NIOInputStream.readInternal(NIOSocketMuxer.java:815) at weblogic.socket.NIOSocketMuxer$NIOInputStream.read(NIOSocketMuxer.java:759)
at weblogic.socket.NIOSocketMuxer$NIOInputStream.read(NIOSocketMuxer.java:742)
at weblogic.socket.JSSEFilterImpl.readFromNetwork(JSSEFilterImpl.java:462)
at weblogic.socket.JSSEFilterImpl.read(JSSEFilterImpl.java:424)
at weblogic.socket.JSSESocket$JSSEInputStream.read(JSSESocket.java:64)

Catastrophic Regexp (again)

Hitting a stuck thread:

"main" prio=5 tid=0x00007fd577005800 nid=0x1c03 runnable [0x00007000035db000]
   java.lang.Thread.State: RUNNABLE
    at java.util.regex.Pattern$5.isSatisfiedBy(Pattern.java:5151)
    at java.util.regex.Pattern$5.isSatisfiedBy(Pattern.java:5151)
    at java.util.regex.Pattern$CharProperty.match(Pattern.java:3694)
    at java.util.regex.Pattern$Curly.match0(Pattern.java:4158)
    at java.util.regex.Pattern$Curly.match(Pattern.java:4132)
    at java.util.regex.Pattern$Start.match(Pattern.java:3408)
    at java.util.regex.Matcher.search(Matcher.java:1199)
    at java.util.regex.Matcher.find(Matcher.java:592)
    at java.util.regex.Pattern.split(Pattern.java:1200)
    at java.lang.String.split(String.java:2313)
    at RegExpTest.main(RegExpTest.java:28)

Once again it's a "stuck" thread for the catastrophic issue in regexp:
https://github.com/devwebcl/regexp-playground/blob/master/src/main/java/cl/devweb/regexp/exploit/JxlsBug.java

Software Architecture Books

List of most important of Software Architecture books:

Software Architecture in Practice (3rd Edition)
Len Bass, Paul Clements, Rick Kazman

Software Systems Architecture: Working With Stakeholders Using Viewpoints and Perspectives (2nd Edition)
Nick Rozanski, Eóin Woods


“Software Architecture: Foundations, Theory, and Practice”
R. N. Taylor, N. Medvidovic, E. M. Dashofy



Design Patterns: Elements of Reusable Object-Oriented Software
Erich Gamma, Richard Helm, Ralph Johnson y John M. Vlissides. 1994













Software Architecture for Developers
Simon Brown


97 Things Every Software Architect Should Know: Collective Wisdom from the Experts



The Mythical Man-Month: Essays on Software Engineering
Frederick P. Brooks Jr.



Software Architecture Pattern
Mark Richards



12 More Essential Skills for Software Architects
Dave Hendricksen


Enterprise Integration Patterns
Gregor Hohpe, Bobby Woolf



Cracking the IT Architect Interview
Sameer Paradkar



Just Enough Software Architecture
George Fairbanks



Building Evolutionary Architectures
Neal Ford, Rebecca Parsons, Patrick Kua



Essential Software Architecture
Ian Gorton


Patterns of Enterprise Application Architecture, 1st Edition
Martin Fowler


Designing Software Architectures: A Practical Approach, 1st Edition
Humberto Cervantes , Rick Kazman


Documenting Software Architectures: Views and Beyond (2nd Edition)
Paul Clements, Felix Bachmann, Len Bass, David Garlan, James Ivers, Reed Little, Paulo Merson, Robert Nord, Judith Stafford


Clean Architecture: A Craftsman's Guide to Software Structure and Design, 1st Edition
Robert C. Martin


Thinking Architecturally
Nathaniel Schutta

37 Things One Architect Knows About IT Transformation: A Chief Architect's Journey
Gregor Hohpe

Evaluating Software Architectures: Methods and Case Studies 1st Ed, 2001
Paul Clements, Peter Gordon, Rick Kazman Mark Klein

Design Patterns: A domain agnostic approach

a book about explaining in a different way GoF patterns, given several examples (use case) by pattern, this way providing a better explanation for each one, this means a leverage for a better understanding, and promoting GoF to a reference book.

A good approach used is to ask himself about different situations, including boundary cases and how each pattern may help or even not help (clarifying common misunderstanding).

A great companion book for Gof, and even Gof becomes as a reference book whereas DPA becomes the book to read.

Analyzing WLS

A very (old) common question is how to analyze (stuck) WLS.

The first we need to do here is to take Heap and Thread Dumps.

Take several Thread dump and one heap dump (although the last one has an embedded thread dump), this will help to find out issues, OOM, connection leaks, recurrent garbage collector, etc.

Heap dump:

jmap -dump:format=b,file=/home/user/tmp/heap.hprof <pid>

kill -3 <pid>

   jstack -l <PID>

i.e.:

Last login: Thu Mar 23 17:57:43 on ttys002
hola$ ps -fea | grep -i weblogic
  501  6179  6178   0  4:04PM ttys001    0:00.00 sh /Users/German/Oracle/Middleware/Oracle_Home/user_projects/domains/base_domain/startWebLogic.sh
  501  6180  6179   0  4:04PM ttys001    0:00.02 /bin/sh /Users/German/Oracle/Middleware/Oracle_Home/user_projects/domains/base_domain/bin/startWebLogic.sh
  501  6225  6180   0  4:04PM ttys001    0:56.60 /Library/Java/JavaVirtualMachines/jdk1.7.0_80.jdk/Contents/Home/bin/java -server -Xms256m -Xmx512m -XX:CompileThreshold=8000 -XX:PermSize=128m -XX:MaxPermSize=256m -Dweblogic.Name=AdminServer -Djava.security.policy=/Users/German/Oracle/Middleware/Oracle_Home/wlserver/server/lib/weblogic.policy -Xverify:none -Djava.endorsed.dirs=/Library/Java/JavaVirtualMachines/jdk1.7.0_80.jdk/Contents/Home/jre/lib/endorsed:/Users/German/Oracle/Middleware/Oracle_Home/wlserver/../oracle_common/modules/endorsed -da -Dwls.home=/Users/German/Oracle/Middleware/Oracle_Home/wlserver/server -Dweblogic.home=/Users/German/Oracle/Middleware/Oracle_Home/wlserver/server -Dweblogic.utils.cmm.lowertier.ServiceDisabled=true weblogic.Server
  501  8061  7485   0 10:08AM ttys002    0:00.00 grep -i weblogic
[German@KDU ~]$ kill -3 6225
[German@KDU ~]$ kill -3 6225
[German@KDU ~]$ kill -3 6225
...
[German@KDU tmp]$ jmap -dump:format=b,file=/Users/German/tmp/heap.hprof 6225
Dumping heap to /Users/German/tmp/heap.hprof ...
Heap dump file created
[German@KDU tmp]$

Other important information would be to retrieve PermGen stats:

$ jmap 28705 -permstat

To get information of variables of java process (including classpath)

jinfo <pid>
